Main Vocals · Vocal Strip

1. Introduction

Main Vocals · Vocal Strip is a dedicated vocal processing environment that combines a fixed Core Strip with a modular FX rack. It is designed for fast, musical vocal mixing with a clear visual layout, real‑time waveform display, and session‑based workflow.

This manual describes the interface, controls, and a suggested workflow so you can get consistent, high‑quality vocal results.

2. System overview

The Main Vocals interface is divided into the following areas:

• Waveform & Transport: Audio display, playback, and navigation.
• Core Strip: Fixed‑order vocal processing modules (Preamp, De‑esser, Gate, Compressors, EQ).
• Modular FX Rack: Flexible chain for additional effects and sound design.
• Session Controls: Save, load, and status of the current session.
• Input/Output & GR Meters: Level and gain‑reduction monitoring.

3. Waveform & transport controls

3.1 Waveform display

The central waveform view shows the currently loaded audio file. You can load audio by dragging and dropping a compatible WAV file directly onto the interface. The waveform updates immediately after loading.

3.2 Transport buttons

3.3 Additional transport features

• Time counter: Shows the current playback position.
• BPM display: Indicates the tempo used for any tempo‑synced features.
• Undo / Redo: Step backward or forward through recent changes.
• Export: Render and export the processed audio file.

4. Core Strip (fixed order processing)

The Core Strip processes the vocal in a fixed sequence. Each module includes an On/Off switch so you can enable only what you need.

4.1 Preamp

• Trim: Adjusts input gain to hit the processing chain at the right level.
• Saturation: Adds harmonic coloration and subtle warmth.
• Phase invert: Flips the signal polarity if needed.

4.2 De‑esser

The De‑esser reduces harsh sibilant sounds such as “S”, “T”, and “Sh”. Use the threshold and frequency controls (where available) to focus on the sibilant range and tame excessive brightness.

4.3 Gate

The Gate attenuates low‑level noise between phrases—useful for room noise, headphone bleed, or breaths. Adjust the threshold so that the vocal opens cleanly while unwanted noise remains reduced.

4.4 Compressor 1

The first compressor is typically used for main dynamic control. Aim for moderate gain reduction to even out performance levels while keeping the vocal natural and expressive.

4.5 Compressor 2

The second compressor can be used for additional control or character—such as more aggressive compression, parallel‑style settings, or limiting peaks after EQ.

4.6 EQ

• Multi‑band EQ: Shape the tone of the vocal by boosting or cutting specific ranges.
• HPF (High‑pass filter): Remove low‑frequency rumble and proximity build‑up.

5. Modular FX rack

5.1 Overview

The Modular FX rack lets you build a custom chain of additional effects. Unlike the fixed Core Strip, modules in the FX rack can be added, removed, and reordered to suit the mix.

5.2 FX rack controls

• Add FX: Insert a new effect module into the rack.
• Clear: Remove all FX modules from the chain.
• A/B chain: Instantly compare two different FX chains.
• Copy A → B / Copy B → A: Duplicate one chain to the other for fine‑tuning and comparison.

6. Session management

6.1 Save session

Use the session save function to store the current state of Main Vocals, including Core Strip settings, FX rack configuration, and other relevant parameters.

6.2 Load session

Load a previously saved session to instantly recall your vocal processing setup for a project or preset workflow.

6.3 Session status

The session status indicator may show:

• Ready: A valid session is loaded and up to date.
• Unsaved: Changes have been made that are not yet saved.
• No file loaded: No audio file is currently loaded into the player.

7. File handling

7.1 Loading audio

• Drag & drop: Drop a .wav file onto the interface to load it.
• The waveform display will update to show the newly loaded file.

7.2 Exporting audio

When you are satisfied with your processing, use the Export function to render the processed audio. Choose your desired file name and destination according to your host or standalone environment.

8. Input, output & gain reduction

8.1 Input / Output meters

Input and output meters allow you to monitor levels before and after processing. Aim to avoid clipping while maintaining a healthy signal level throughout the chain.

8.2 GR (Gain Reduction) meter

The Gain Reduction meter shows how much level is being reduced by the compressors in the Core Strip. Use it to visually confirm that compression is working as intended and not over‑squashing the vocal.

9. Engine information

The engine can be summarized as:

• Player: Transport‑based playback of the loaded audio file.
• Core: Fixed‑order vocal processing modules.
• FX: Modular rack for additional effects.
• Session: Save/load system with status indication.

10. Example workflow

1. Load audio: Drag and drop a WAV file onto the interface.
2. Set input level: Use the Preamp Trim so the input meter peaks at a healthy level.
3. Clean up: Enable the Gate and De‑esser to reduce noise and sibilance.
4. Control dynamics: Use Compressor 1 for main control and Compressor 2 for extra shaping if needed.
5. Shape tone: Use EQ and HPF to remove rumble and enhance clarity and presence.
6. Add FX: Build a chain in the Modular FX rack for space, color, or creative effects.
7. Compare: Use A/B chains in the FX rack to compare different approaches.
8. Save session: Store your setup so you can recall it later.
9. Export: Render the processed vocal to a new audio file.

11. Copyright

© 2027 SKAN — All Rights Reserved.

Website: skansdream.com
